10Ton Diesel Counterweight Forklift Truck
10Ton Diesel Counterweight Forklift Truck
10Ton Diesel Counterweight Forklift Truck
10Ton Diesel Counterweight Forklift Truck
10Ton Diesel Counterweight Forklift Truck
Email

10Ton Diesel Counterweight Forklift Truck

Description of products:

Along with the kind of engineering that promises unsurpassed performance and productivity in all applications, heavy-duty forklift trucks are designed with many features that facilitate maintenance and servicing.

Applications:

As lifting and transporting machineries, 10Ton Diesel counterweight Forklift Truck is widely used for loading, unloading and transporting the packaged goods in the construction site, factories, warehouses, stations, wharves, ports and so on. With other attachments of forklift trucks, it can be used for the handling of the bulk goods and unpackaged goods.

Technical Parameter

GeneralModel CPCD100
Rated capacity kg 10000
Load center mm 600
Power type Diesel
Transmission Hydraulic
Dimensions Lifting height mm 3000
Free lifting height mm 195
Turning radius mm 3900
Overall length mm 5480
Overall width mm 2275
Overall height (mast lowered) mm 2850
Overall height (mast raised) mm 4297
Overall height (overhead guard) mm 2585
Fork length mm 1220
Fork width mm 175
Fork thickness mm 80
Performance Max. driving speed (with/without load) km/h 16/22
Max. lifting speed (with load) mm/s 310
Max. traction (with/without load) kn 57
Gradeability (with/without load) % 19/20
Tilting angles (forward/backward) ° 6/12
Service weight kg 12510
Engine Engine model CHAOCHAI6102-BG
Power kW 80.9
Rated speed rpm 2500
Displacement L 5.785
No. of cylinder 6
Wheel Front overhang mm 718
Wheel base mm 2500
Front tread mm 1600
Rear tread mm 1700
Front tire 9.00-20-14
Rear tire 9.00-20-14

10tons Diesel Forklift Advantages:

1. Scientific ergonomics design.

2. Adjustable safety seat.

3. Wide-view mast.

4. High- mount exhaust system.

5. Flexible steering system.

6. Power-assisted brake.

7. Optimal heat radiating& air duct system.

8. Hydraulic transmission system.

9. Easy available toolbox.

10. Maintenance-free battery

FEATURES:

With over 30 years forklift trucks manufacturing, we brought the heavy-duty long life 8-10t trucks to customers.

COMFORTABLE OPERATION

Spacious operator cabin with very low vibration and noise, as well as clean air, are enjoyed by operators.

RELIABILITY

By focusing on enhancing reliability, reducing downtime, the 8-10t forklift trucks are able to make the greater productivity for customer.

EASY MAINTENANCE

Along with the kind of engineering that promises unsurpassed performance and productivity in all applications, heavy-duty forklift trucks are designed with many features that facilitate maintenance and servicing.

If you have any other questions, please contact us directly. Our forklift are all with high quality, and you can choose any other engine to equip. It can be produced according to your idea. And we invite you to visit our factory.
